pip install mystmd
# or
npm install -g mystmd

---
title: Your Article Title
authors:
  - name: Your Name
    email: you@university.edu
    corresponding: true
    orcid: 0000-0000-0000-0000
    affiliations:
      - id: univ
        name: Your University
    roles:
      - Conceptualization
      - Methodology
keywords:
  - keyword1
  - keyword2
abstract: |
  Your abstract text here.
exports:
  - format: pdf
    template: path/to/elsarticle-myst
    output: article.pdf
    columns: single
---

# Introduction

Your content here...

myst build your-article.md --pdf

magick your-abstract.png -depth 8 your-abstract.png    # keeps transparency

title: Article Title
subtitle: Optional Subtitle              # rendered below main title
short_title: Short Title                 # running header (LaTeX specials auto-escaped)
authors:
  - name: Author Name
    email: author@example.com
    orcid: 0000-0000-0000-0000
    corresponding: true                  # tagged with \cormark and "Corresponding author" footnote
    equal_contributor: true              # 2+ such authors share a single "contributed equally" footnote
    deceased: false                      # rendered as a dagger superscript via deceased= option
    note: Author-specific footnote text  # auto-numbered \fnmark on author, \fntext at bottom of page
    twitter: username                    # routed through \author options alongside facebook/linkedin
    facebook: https://facebook.com/user  # full URL
    linkedin: https://linkedin.com/in/u  # full URL
    affiliations:
      - institution-id
    roles:                               # CRediT taxonomy; LaTeX specials auto-escaped
      - Conceptualization
      - Writing - original draft
affiliations:
  - id: institution-id
    name: Institution Name               # LaTeX specials auto-escaped on all string fields
    department: Department
    city: City
    country: Country
keywords:
  - keyword1
  - keyword2
abstract: |
  Abstract text. Markdown formatting and inline LaTeX math both work.
keypoints:                               # Research highlights (3-5 items, rendered as \item list)
  - First key finding
  - Second key finding
parts:
  title_note: Funding acknowledgment.    # plain text; auto-escaped
  note: General disclaimer.              # plain text; auto-escaped
  acknowledgments: Thanks to reviewers.  # plain text; first-page \nonumnote
  # biography goes in a +++ block in the body, and appendices go in the body
  # as raw \appendix. Neither belongs here. See "Document Parts" below.
bibliography:
  - references.bib

parts:
  title_note: Prepared with support from grant XYZ-12345.     # plain-text footnote on title
  note: Authors declare no competing interests.               # plain-text frontmatter note
  acknowledgments: We thank the editor and two reviewers.     # plain-text first-page note

+++ {"part": "biography"}

```{raw} latex
\bio{}
Author One develops open-source computational tools.
\endbio
\bio{}
Author Two is a professor of economics.
\endbio

The same pattern works for `parts.highlights` when you need finer-grained LaTeX control than the YAML-list-based `keypoints` frontmatter offers, and for `parts.graphical_abstract` when you want raw LaTeX rather than a file path.

> **Why two locations?** MyST processes part values through its markdown pipeline before injecting them into the template. A YAML scalar with literal `\bio{}` becomes `\textbackslash bio\{\}` in the rendered LaTeX. The `+++ {"part": ...}` block with a nested `{raw} latex` directive bypasses that pipeline.

### Appendices

Appendices go in the **body**, not in a `parts:` entry. Open one with a raw `\appendix`, then write ordinary headings or include a separate file:

````markdown
```{raw} latex
\appendix

Sections after `\appendix` are lettered A, B, C. `example/sample-article.md` does exactly this.

The template has no `parts.appendix` key, and adding one back would reintroduce a silent bug. MyST excludes frontmatter parts from the rendered document and harvests the `.bib` from that document, so a work cited only inside an appendix part reaches the `.tex` and never the `.bib`: an undefined citation that renders as `?` while every build step exits 0. A frontmatter part's headings are also demoted one level, which drops the appendix letter and prints `A.1` as `.1`. Both are upstream mystmd behaviour ([#3032](https://github.com/jupyter-book/mystmd/issues/3032), [#3034](https://github.com/jupyter-book/mystmd/issues/3034)); the body-level form avoids both. `example/appendix.md` cites one work that nothing else cites, so CI keeps testing this path.

### Known upstream limitations

Three mystmd bugs are reachable from this template. All are silent: `myst build` exits 0 and produces a PDF. Measured on mystmd 1.10.1.

> **These entries expire on someone else's merge.** Two have open PRs. When the PR lands, the entry becomes *obsolete* rather than wrong, and nothing in CI will say so — a gate can catch a claim that has become false, but not one that has become unnecessary. **Re-run the probes in each entry whenever the pinned mystmd version changes**, and delete any entry whose bug no longer reproduces.

**Four `prf:` kinds vanish from the PDF** ([#3030](https://github.com/jupyter-book/mystmd/issues/3030), PR [#3031](https://github.com/jupyter-book/mystmd/pull/3031)). `algorithm`, `assumption`, `criterion` and `property` match no case in `myst-to-tex`'s `kindToEnvironment`, so the block **and its `\label`** are omitted, while any `\ref` to it is still emitted and resolves to `??`. The other eleven kinds are fine. This template ships `algorithm` and `algpseudocode`, so writing `:::{prf:algorithm}` is a natural thing to try, and the body simply disappears. Until the PR lands, write algorithms as a `{raw} latex` block (see below) or use a supported kind.

**Citations inside a frontmatter part never reach the `.bib`** ([#3032](https://github.com/jupyter-book/mystmd/issues/3032), PR [#3033](https://github.com/jupyter-book/mystmd/pull/3033)). MyST excludes `parts:` from the rendered document and harvests the bibliography from that document. A work cited only in `parts.abstract` reaches the `.tex` and never the `.bib`: an undefined citation rendering as `?`. This is why `parts.appendix` was removed (see "Appendices"), but `parts.abstract` is still exposed — cite in the body, not in the abstract.

**`[Sec %s](#label)` bakes a literal `??` into the `.tex`** ([#3035](https://github.com/jupyter-book/mystmd/pull/3035)). Single-article exports set the article level to 0, and the numbering lookup then computes a key no configuration can enable. The `??` is plain text, not a failed `\ref`, so **no LaTeX warning fires** and the compile-log gate cannot see it. `scripts/check-content.sh` greps the PDF text for `??` for exactly this reason.

### Raw LaTeX: which fence

Two forms, and they are not interchangeable.

| Form | Behaviour |
|---|---|
| ```` ```{raw} latex ```` (argument) | Stored in both `value` and `tex`. mystmd parses it, so the HTML site renders it *and* the LaTeX export writes it verbatim. Use for content the site should show: tables, figures, paragraphs. |
| `:::{raw:latex}` (colon) | Stored as `tex` only. Correct in the PDF, **invisible on the site**. Use for anything that only steers LaTeX: `\appendix`, counter redefinitions, `\bio`/`\endbio`. |

Put a macro mystmd's LaTeX parser does not know in the argument form and it emits `Unhandled TEX conversion for node of "macro_x"`. Measured on mystmd 1.10.1: the **macro node** is dropped, but the surrounding content is not — a `\bio{}`-wrapped paragraph and a `\legend`-annotated table both still reach the site in full, and the PDF is correct either way. So the message ranges from cosmetic to a lost element depending on what the macro carried, and it is worth reading rather than silencing.

This template's biography part carried `\bio`/`\endbio` in the argument form and produced 24 such errors per build. Moving it to the colon form removed all 24 with byte-identical PDF text, at no cost because a frontmatter part never reaches the site anyway. CI now fails on that message.

**If you add a raw block and CI goes red here, weakening the gate is the wrong fix.** Check first whether the block is content the site should show. If it is (a table, a figure, a paragraph), keep the argument form and narrow the gate to the specific macro, as the sibling `econsoc_template` does with `macro_(begin|end)`. If it only steers LaTeX, move it to the colon form and the message goes away on its own.

A bare `\appendix` parses cleanly in either form, so the appendix block in `example/sample-article.md` is left as-is.

### Escaping

The template escapes LaTeX specials in the frontmatter strings it interpolates itself. Which fields those are is not guessable from the template source, because MyST **promotes** some frontmatter keys to rendered parts and hands them to jtex already converted to LaTeX. Promotion, not template syntax, decides the side a field falls on: `abstract` written as a plain YAML scalar arrives escaped, while `title` in the same file arrives raw.

| Field | Handling |
|---|---|
| `abstract`, every `parts.*`, body content | Escaped by MyST. The template must **not** touch these; a second pass emits `\textbackslash{}%` and prints it literally. |
| `title`, `subtitle`, `short_title`, `keywords` | `esctext()`: `&`, `%` and `#` only, so `$x_1$` and `$\alpha$-mixing` still typeset. A literal `_` outside mathematics must be written `\_`. |
| `authors[].name`, `.note`, `.roles`, all `affiliations[].*`, `tags` (JEL), `venue.title` | `esc()`: every special. These never carry mathematics. |
| `authors[].email`, `.url`, `.orcid`, social links | Verbatim. Escaping `_` or `%` breaks the link the class builds. A literal `%` or `#` here breaks the build; percent-encode it. |

`&` is the character that matters most in economics (R&D, Q&A, "Risk & Return", institutional names) and it fails **silently**: unescaped, `Risk & Return` typesets as `Risk Return` and a `K&W` keyword as `KW`. An unescaped `%` is worse, because it comments out the rest of the line including the closing brace, and the field vanishes from a PDF that still ships.

`scripts/check-escaping.sh` asserts all three columns on every CI run, and `--self-test` seeds both a raw and a doubly-escaped fixture to prove the checker can fail.

### What CI asserts

| Gate | Why it is not redundant |
|---|---|
| `jtex check` | Keeps `packages:` honest; a missing entry means MyST re-emits a `\usepackage` the class already loaded. |
| `verify-upstream.sh` + `--self-test` | The vendored classes differ from upstream by exactly the patches in `PATCHES.md`. A `skip` line is treated as an error, since a skipped check reads as a pass. |
| `check-escaping.sh` + `--self-test` | The escaping was documented and never asserted for six releases, during which `title` was raw. |
| Compile-log grep | latexmk's exit code is not enough: mystmd prints "Exported PDF" and copies the file after xelatex exits non-zero. `^!` is TeX's fatal-error convention; undefined references and citations are only warnings but render as `?`. natbib prefixes its warnings `Package natbib Warning:`, not `LaTeX Warning:`, so the pattern matches the bare `Warning: Citation` form. |
| bibtex gate on `build.stdout.log` | mystmd deletes the `.blg` with the other aux files. A positive control requires `This is BibTeX` in the log, so the gate cannot pass by bibtex never running. |
| `Template render error` / `TypeError` / `Unhandled TEX conversion` on `build.stdout.log` | A jtex failure happens before LaTeX runs, so no compile log exists to grep. mystmd prints "Exported TeX", *then* the error, then exits 0 — leaving the previous PDF on disk with a stale mtime, which every later gate then "verifies". `Unhandled TEX conversion` was originally excluded because it fired 24 times on a healthy build; that turned out to be a real defect rather than noise. See "Raw LaTeX: which fence" below. |
| `check-escaping.sh` absent-field fixtures | A fixture that supplies every field cannot catch a field being *absent*. MyST only warns on an author with no `name`, so it reaches the template, where a property access on undefined aborts the render and an unfiltered loop emits its separator anyway (`\shortauthors{, Solo}`). Six cases, both classes, including a page that declares nothing and inherits project scope. |
| `check-content.sh` `??` check | An unresolved cross-reference. Two of the ways it arises raise no LaTeX warning at all (see "Known upstream limitations"), so the compile-log gate is structurally unable to catch them. |
| `check-content.sh` + `--self-test` | Every other gate asks whether the build *succeeded*; this one asks what it *produced*. It diffs `pdftotext` output against committed snapshots in `example/exports/snapshots/`. Nothing else would have caught the appendix headings shipping as `.1. Supplementary Methods` and the appendix table as `Table .5`. A snapshot diff is *expected* to fail when the sample or template changes on purpose — read the diff, then re-record with `--update` in the same commit. |
| double-blind positive control | The blinding gate is an *absence* assertion keyed on a hard-coded surname. Renaming the example's authors would leave it green and vacuous forever, so it now first asserts the surname *does* appear in the unblinded export. |
| `check-ink.sh` | A blank graphical abstract passes every other gate: exit 0, no LaTeX error, and `pdfimages` lists the image as present. |
| `endfloat` / `doubleblind` effect checks | `class_options` reach the class unvalidated, and elsarticle's `endfloat` sits behind an `\IfFileExists` with an empty else-branch: without `endfloat.sty` the option silently does nothing. Assert the effect, not the flag. |

## Files Included

| File | Description |
|------|-------------|
| `template.tex` | Main Jinja/jtex template |
| `template.yml` | Template configuration |
| `cas-sc.cls` | Single column document class (**patched**, see `PATCHES.md`) |
| `cas-dc.cls` | Double column document class (**patched**, see `PATCHES.md`) |
| `cas-common.sty` | Shared style definitions (**patched**, see `PATCHES.md`) |
| `cas-model2-names.bst` | Bibliography style (author-year and numeric) |
| `example/` | Complete working example |
| `PATCHES.md` | Documents every modification to the upstream Elsevier files |
| `LICENSE`, `LICENSE-CONTENT`, `LICENSE-LATEX` | MIT for code, CC-BY-4.0 for prose, LPPL-1.3c for class files |

## Supported LaTeX Packages and Environments

The template includes comprehensive package support for scientific writing:

### Mathematics (amsmath, mathtools)
- `align`, `align*`, `alignat`, `flalign` - Aligned equations
- `gather`, `gather*` - Centered equation groups
- `multline`, `multline*` - Multi-line equations
- `subequations` - Equation sub-numbering
- `pmatrix`, `bmatrix`, `vmatrix`, `Vmatrix` - Matrix brackets
- `pmatrix*`, `bmatrix*`, `vmatrix*`, `Vmatrix*` - Matrix brackets with alignment (mathtools)

### Figures (graphicx, caption, subcaption, wrapfig, rotating)
- `figure`, `figure*` - Standard figures
- `subfigure` - Sub-figures with individual captions
- `wrapfigure` - Text-wrapped figures
- `sidewaysfigure` - Rotated full-page figures

### Tables (array, booktabs, tabularx, longtable, threeparttable)
- `table`, `table*` - Standard tables
- `tabular` - Basic table environment
- `tabularx` - Tables with auto-width columns
- `longtable` - Multi-page tables
- `threeparttable` + `tablenotes` - Tables with footnotes
- `sidewaystable` - Rotated full-page tables

### Lists (enumitem)
- `enumerate` - Numbered lists
- `itemize` - Bulleted lists
- `description` - Description lists

### Quotations (csquotes)
- `quote`, `quotation` - Standard quote blocks
- `displayquote` - Enhanced quotations with attribution

### Algorithms (algorithm, algorithmicx)
- `algorithm` - Algorithm float environment
- `algorithmic` - Algorithm pseudocode (via algpseudocode)

### Page Layout (changepage, pdflscape)
- `adjustwidth` - Adjust margins
- `landscape` - Landscape page orientation
- `minipage`, `center`, `centering` - Layout control

### Boxes (adjustbox)
- `adjustbox` - Scale, trim, and adjust content

### Additional Packages
- `hyperref` - Hyperlinks and PDF metadata
- `xcolor`, `colortbl` - Colors in text and tables
- `multirow`, `makecell` - Complex table cells
- `natbib` - Citation management
- `csquotes` - Context-sensitive quotation marks

## Example

See the `example/` directory for a comprehensive demonstration including:

- Typography (formatting, footnotes, definition lists)
- Mathematics (inline, display, custom macros)
- Formal environments (definitions, theorems, proofs)
- Admonitions (notes, warnings, tips, etc.)
- Tables (markdown, list-table, csv-table, raw LaTeX)
- Code blocks with syntax highlighting
- Figures and cross-references
- Citations and bibliography

Build the example:

```bash
cd example
myst build sample-article.md --pdf
```

## Credits

Based on the official [Elsevier CAS LaTeX templates](https://www.elsevier.com/authors/policies-and-guidelines/latex-instructions). The original LaTeX classes are copyright Elsevier Ltd and distributed under the LaTeX Project Public License (LPPL-1.3c).

## License

| Component | License | File |
|---|---|---|
| Template configuration (`template.tex`, `template.yml`, `myst.yml`) | [MIT](https://opensource.org/licenses/MIT) | `LICENSE` |
| Documentation prose, example narrative | [CC-BY-4.0](https://creativecommons.org/licenses/by/4.0/) | `LICENSE-CONTENT` |
| Elsevier CAS classes (`*.cls`, `cas-common.sty`, `*.bst`) | [LPPL-1.3c](https://www.latex-project.org/lppl/lppl-1-3c/) | `LICENSE-LATEX` |

The class files are patched copies of the upstream Elsevier bundle. The LPPL requires that modified files be clearly identified; `PATCHES.md` enumerates every modification and the original upstream copies are preserved verbatim in `original/els-cas-templates.zip`.
